SI21 Solar Pump VFD Manual
19
● Motor Parameters
Parameter
(address)
Function
Description
Range of settings and definition
Factory default
(setting range)
Notes
F02.00(0x0200
)
Motor type
V/F SVC
Set the type of motor
0: Asynchronous motor (AM)
1: Reserved
0
(0～1)
F02.01(0x0201
)
Pole number
V/F SVC
Set the number of motor stages.
4
(2～98)
F02.02(0x0202
)
Motor rated
power
V/F SVC
Set the rated power of the motor.
Model setting
(0.1kW～
1000.0kW)
F02.03(0x0203
)
Motor rated
frequency
V/F SVC
Set the rated frequency of the motor.
Model setting
(0.01Hz～
Maximum
frequency)
F02.04(0x0204
)
Motor rated
speed
V/F SVC
Set the rated speed of the motor.
Model setting
(0rpm～
65000rpm)
F02.05(0x0205
)
Motor rated
voltage
V/F SVC
Set the rated voltage of the motor.
Model setting
(0V～1500V)
F02.06(0x0206
)
Motor rated
current
V/F SVC
Set the rated current of the motor.
Model setting
(0.1A～
3000.0A)
F02.07(0x0207
)
Motor
parameter
auto-tuning
selection
V/F SVC
After the parameter auto-tuning is
completed, the set value of [F02.07] will be
automatically set to "0".
0: No operation
1: Rotary self-tuning
2: Static self-tuning
3: Stator resistance self-tuning
0
(0～3)
S/T2
models do
not
support
parameter
auto-tunin
g
F02.50(0x0232
)
Motor online
learning
function
selection
V/F SVC
0: Invalid
1: Power-on self-learning
2: Run the initial segment self-learning
3: Self-learning in operation
0
(0～3)
S/T2
models do
not
support
motor
online
learning
