SI21 Solar Pump VFD Manual
22
3: Reserved
4: Reserved
F06.01(0x0601
)
AO output
selection
V/F SVC
0: Given frequency
1: Output frequency
2: Output current
3: Input voltage
4: Output voltage
5: Mechanical speed
6: Given torque
7: Output torque
8: PID given
9: PID feedback amount
10: Output power
11: Bus voltage
12: VS input value
13: AI input value
14: AS input value
15: PUL input value
16: Module temperature 1
17: Module temperature 2
18: 485 communication given
19: Virtual terminal vY1
0
(0～19)
F06.20(0x0614
)
Output
terminal
polarity
selection
V/F SVC
0: Positive polarity 1: Negative polarity
LED "0" digit: Y terminal
LED "00" digit: Relay output terminal 1
LED "000" digit: Reserved
LED "0000" digit: Reserved
0000
(0000～1111)
F06.21(0x0615
)
Output
terminal Y
V/F SVC
See terminal Y function
1
(0～63)
F06.22(0x0616
)
Relay 1 output
(TA-TB-TC)
V/F SVC
See terminal Y function
4
(0～63)
● Start/Stop Control
Parameter
(address)
Function
Description
Range of settings and definition
Factory default
(setting range)
Notes
F07.05(0x0705
)
Direction of
rotation
V/F SVC
LED "0" digit: Reverse the running
direction
0: The direction is unchanged
1: Direction reversal
0000
(0000～1111)
