SI21 Solar Pump VFD Manual
28
Parameter
code (address)
Function
Description
Content
Signal level of multi-function analog
output
Notes
C00.00
(0x2100)
Given frequency
V/F
SVC
10V corresponds to the maximum
frequency (60Hz)
C00.01
(0x2101)
Output frequency
V/F
SVC
10V corresponds to the maximum
frequency
C00.02(0x2102)
Output current
V/F
SVC
10V corresponds to the rated current of the
double motor (5A)
C00.03
(0x2103)
Input voltage
V/F
SVC
10V corresponds to 380V
C00.04
(0x2104)
The output voltage
V/F
SVC
10V corresponds to the rated voltage of the
motor 360V
C00.05
(0x2105)
Mechanical speed
V/F
SVC
10V corresponds to the maximum
frequency of mechanical speed
C00.08
(0x2108)
PID given
V/F
SVC
10V corresponds to 100%
C00.09
(0x2109)
PID feedback
V/F
SVC
10V corresponds to 100%
C00.10
(0x210A)
Output Power
V/F
SVC
C00.11
(0x210B)
Bus voltage
V/F
SVC
5V corresponding rated bus voltage
C00.12
(0x210C)
Module temperature 1
V/F
SVC
10V corresponds to 100℃
C00.14
(0x210E)
Input terminal X is on
V/F
SVC
C00.15
(0x210F)
Output terminal Y is
on
V/F
SVC
C00.16(0x2110)
Analog AI input value
V/F
SVC
10V corresponds to 10V
C00.20
(0x2114)
Analog output AO
V/F
SVC
C00.23
(0x2117)
Power-on running
time
V/F
SVC
C00.24
(0x2118)
Accumulated running
time of the machine
V/F
SVC
C00.25
(0x2119)
VFD power level
V/F
SVC
C00.26
(0x211A)
VFD rated voltage
V/F
SVC
C00.27
(0x211B)
VFD rated current
V/F
SVC
C00.28
(0x211C)
Software version
V/F
SVC
● Fault Monitor
Parameter
code (address)
Function Description
Content
Signal level of
multi-function
analog output
Notes
C01.00
(0x2200)
Fault type diagnostic information
V/F SVC
C01.01
(0x2201)
Troubleshooting information
V/F SVC
C01.02
(0x2202)
Fault operating frequency
V/F SVC
C01.03
(0x2203)
Fault output voltage
V/F SVC
C01.04
(0x2204)
Fault output current
V/F SVC
C01.05
(0x2205)
Fault bus voltage
V/F SVC
