Velleman DEM106 User Manual

DEM106
V. 01 – 07/05/2015 5 ©Velleman nv
Display
1
MIN
8
data hold
2
MAX
9
AVG
3
battery level
10
K/J-type mode
4
°C/°F
11
auto power-off
5
T1 reading
12
T2 mode
6
°C/°F
13
T1-T2 mode
7
T2/T1-T2 reading
14
T1 mode
6. Battery
This device is battery-operated, using 1x 9 V battery. Replace it when the
battery-low icon appears.
To replace the battery, proceed as follows:
1. Switch off the device.
A malfunction may occur if you replace the batteries while the
device is on.
2. Open the battery compartment.
3. Replace the battery with a new 9 V battery.
4. Close the battery compartment.
Warning: Do not puncture batteries or throw them in fire as they
may explode. Do not attempt to recharge non-rechargeable
batteries (alkaline). Dispose of batteries in accordance with local
regulations. Keep batteries away from children.
7. Operation
1. Connect the thermocouples to the meter.
2. Switch on the meter.
3. Press the setting button to select the K-type or J-type thermocouple.
4. Press the backlight button to switch the backlight on or off.
5. Press the °C/°F mode button to switch between °C and °F.
6. Connect the tip of the thermocouple to the object to be measured. The
measured temperature appears on the LCD display.
7. Press the T2/T1-T2 button to display the difference between the
measured values of T1 and T2.
8. Briefly press the data hold button to freeze the reading on the display.
Press again to unfreeze.
9. Press the AVG button to display the average recorded values.
10. Press the MIN/MAX button to display the recorded maximum value,
briefly press to display the recorded minimum value, hold pressed to
exit the function.
11. Hold the power switch pressed to switch off the meter.
