DVM601
22/08/2013 ©2008 Velleman
®
Components nv
10
input impedance 10Mohm
frequency range 50 to 400Hz
maximum input 600Vac
DC current 400µ/4m/400m/10A
basic accuracy ± 1.0% of rdg ± 2 digits for 400µA~4mA range/ ±
1.2% of rdg ± 2 digits for 400mA range / ± 2.0%
of rdg ± 5 digits for 10A range
overload protection 500mA/600V fuse & 10A/600V fuse
AC current 400µ/4m/400m/10A
basic accuracy ± 1.2% of rdg ± 2 digits for 400µA~4mA range/ ±
1.5% of rdg ± 2 digits for 400mA range / ± 2.0%
of rdg ± 5 digits for 10A range
overload protection 500mA/600V fuse & 10A/600V fuse
resistance 400/4k/40k/400k/4M/40M
basic accuracy ± 1.5% of rdg ± 4 digits for 400 ohms range / ±
1.5~2.0% of rdg ± 2 digits for 4k~40M range
overload protection 15 seconds max. 250V on all ranges
capacitance 50.00nF/500.0nF/5.000uF/50.00uF/100.0uF
accuracy ±3.0~5.0% of rdg ± 5~7 digits
frequency 5Hz/50Hz/500Hz/5KHz/50KHz/500KHz/10MHz
basic accuracy ±1.2% of rdg ± 3digits
overload protection 250V AC or DC
maximum display 3999
power supply 9V battery (E-block)
dimensions 170 x 78 x 48mm
weight (with battery) approx. 330g
Use this device with original accessories only. Velleman nv cannot be held
responsible in the event of damage or injury resulted from (incorrect) use
of this device. For more info concerning this product, please visit our
website www.velleman.eu.
The information in this manual is subject to change without prior notice.
© COPYRIGHT NOTICE
This manual is copyrighted. The copyright to this manual is owned by Velleman Components
nv. All worldwide rights reserved. No part of this manual may be copied, reproduced, translated or
reduced to any electronic medium or otherwise without the prior written consent of the copyright
holder.
