DVM895
V. 01 – 28/11/2017 11 ©Velleman nv
20 MΩ
10 kΩ
± (1.5 % rdg + 3 digits)
200 MΩ
100 kΩ
± (5.0 % rdg + 5 digits)
Overload protection: 600 V DC or AC rms
9.6 CAPACITANCE
Do not conduct capacitance measurements on live
circuits
range
resolution
accuracy
2000 pF
1 pF
± (2.5 % rdg + 10 digits)
20 nF
10 pF
± (2.5 % rdg + 5 digits)
200 nF
100 pF
2 µF
1 nF
20 µF
10 nF
200 µF
100 nF
± (5.0 % rdg + 10 digits)
Overload protection: F0.5 A/600 V fuse
9.7 DIODE AND CONTINUITY
Do not conduct diode or continuity measurements on
live circuits
range
description
test condition
display reads the
approximate forward
voltage of the diode
forward DC current ± 1 mA
reversed DC voltage ± 3 V
built-in buzzer sounds
if resistance < 50 Ω
open-circuit voltage ± 3 V
Overload protection: 600 V DC or AC rms
9.8 FREQUENCY
Do not conduct frequency measurements on live circuits
range
resolution
accuracy
20 kHz
10 Hz
± (2.0 % rdg + 5 digits)
Sensitivity: sine wave 0.5 V rms
Overload protection: 600 V DC or AC rms
