Features & Specifications
Features:
14 different functions including timers, switching, flashing, interval, random switching, …
Two pre-programmed delays.
Learning mode for delays of 2s up to 12 days.
EEPROM for delay time storage in case of power failure.
On-board transient filter for the relay contacts.
Suitable for control of incandescent lighting, halogen lighting, fluorescent lighting, fans, valves, buzzers, …
Specifications:
Operating voltages : 9-12 VAC or 12 VDC.
Max. load : 2.5A (550W/220V; 275W/110V).
Dimensions pcb (wxdxh): 65 x 57 x 25mm.
