Velleman K8059 - Capacitor Mounting; Integrated Circuit (IC) Placement

7
Construction
 T1 : MPSH10
10. Transistor
 +
 -
 Check for good attachment of
the solder to the contacts
7. Battery contacts
 C1 : 1pF (1)
 C2 : 4p7 (4.7)
 C3 : 100pF (101)
 Bend C3 away from the LED
 C4 : 100pF (101)
 C5 : 100pF (101)
 C6 : 100nF (104)
9. Capacitors
 IC1 : VK8059
VK8059=(Programmed PIC12F629)
 Pay attention to the position
of the notch!
11. IC. Pay attention to the
notch !
Affix the supplied sticker to the
back of the housing.
12. Sticker
Velleman
SRFCE
433,92 MHz
 LD1 : 3mm blue
8. LED
COLOR= 2...5
LD.
CATHODE
8mm
LD...
-
+
