Velleman KSR13 - Gearbox Testing and Troubleshooting

Prepare the below parts first before you
test the “Gear box” and “Solar panel”.
01 Assembly 03 Testing
04 Trouble shooting
02 Wiring
Body Head C6 X2
(Gear Box) (Solar Panel)
Testing : You need to test the gear box first.
8
Head
Body
C6
C6
Positive
Negative
RED
BLACK
SUN
OR
50W & UP
HALOGEN
Make sure C6 is turning !
If C6 does not work,
Please disassemble the gear box,
and back to the page 4.
FRONT
