MONCOLHA5PN6
24.11.2009 ©Velleman nv
4
4. Features
• full remote control for adjustment of: brightness, colour, contrast
• 2 video inputs (one with audio)
• OSD (On-Screen Display)
• PAL/NTSC system
• image can be switched left/right and up/down
• comes with: remote control, cable, table stand, headrest installation frame
5. Description
Refer to the illustrations on page 2 of this manual.
front panel
1 “+” button to increase the entered values
2 menu button to select the various adjustments
3 “-” button to reduce the entered values
4 power button to activate/deactivate the device
5 remote control sensor
6 headphones connection
remote control
a ON/OFF button d contrast adjustment
b brightness adjustment e volume up/down
c colour adjustment f Video1/2 channel selection button
g system button sys1 provides normal viewing for video1 and 2
sys2 provides normal viewing for video1 and mirrored viewing for video2.
6. Wiring
• Connect the supplied cable with the monitor’s mini-DIN plug.
• yellow RCA = video 1
• red RCA = video 2
• white RCA = audio (only for video 1 channel)
• black = power (pin = + ; ring = -)
7. Operation
Refer to the illustrations on page 2 of this manual.
• Make sure the video and audio input connections are properly executed (see “6. Wiring”).
• Press 'MENU' [2] to display the adjustments in this order: Brightness → Colour → Contrast →
LEFT/RIGHT → UP/DOWN → exit menu. Enter the values with '∧' [1] and '∨' [3].
• The power button [4] activates/deactivates the LCD monitor. It is not necessary to disconnect
the power adapter.
• The speaker is switched off when headphones are connected.
