4. To prevent loss, place the
camera battery chamber
cover in the BG-C8
battery chamber holder,
as indicated above. Swing
the battery chamber cover
shut so that it locks into
place
5. Remove the protective
cap and connect the BG-
C8 grip to the camera
while aligning the grip’s
mounting screw with the
camera’s tripod socket.
6. Rotate the attachment
wheel in the direction
shown by the arrow until it
is firmly tightened.
1
2
3
Turn the camera power off,
remove batteries, and replace
protective contact cap when
removing the grip.
1
2
3
