VENOM HSS2006 - Controls and Features Identification

- 5 -
Read this owner’s manual before operating the equipment. Familiarize yourself with the location and
function of the controls and features. Save this manual for future reference.
1) Beam - 6” extra wide flange.
2) 8” Wedge - Features wedge wings and tapered ends making splitting easier.
3) Oil Tank
4) Tires - Maximum rated towing speed is 45 MPH.
5) Engine - Air cooled 208cc engine powers the hydraulic pump
6) Support Leg- Supports the log splitter while operating.
7) Tow Bar- Move with ATV & Lawn/Garden Tractor
8) Safety Chains - Safety feature to prevent loss of log splitter while towing.
9) 50mm Coupler – Attaches the log splitter to the 50mm ball.
10) Hydraulic Cylinder –4” bore and 23-1/4” stroke, rated to 3600 psi.
11) Control Valve Lever – Controls the forward and backward movement of splitting wedge
12) Log Cradle
13) Fender
Controls and Features Identification
