8
Note: In calm water, the sonar sensor can be
set at a level which will provide the maximum
amount of sonar coverage. In rough water, the
sonar sensor may need to be lowered into the
water further to provide stabilized readings.
USING THE FISH FINDER WITH FLOAT
1. Place the sonar sensor and float in your hand, and toss
underhand. Do not throw the sensor by the cable as this
will cause irreparable damage.
2. Use a pole to guide the sonar sensor to a desirable
position
3. Add a float kit on the cable to allow the cable to float on
top of the water.
4. Neatly wind up the excess cable.
Note: 1. If you do not have a need for the sonar sensor
float, it can be removed. 2. Do not allow the cable to sink
to the bottom as it may become entangled in debris.
USING THE FISH FINDER WITH ADAPTER
Your fish finder includes a combination Side-Scan
adapter & mounting bracket for the Sonar Sensor.
A. The Adapter includes mounting bracket so that you can
attach it to any flat surface or boat hull.
B. The Adapter is removable and adjustable up to 180
Degrees.
