INSTALLATION/USE/MAINTENANCE GUIDE
LEGENDA
PE Earth (yellow/green) I Minimum speed
M Fan motor II Medium speed
N Neutral III Maximum speed
L Phase SDP Power card
Com Common (white) XA1 Connection box
Fig. 16
Fig. 15
LEGENDA
PE Earth (yellow/green) I Minimum speed
M Fan motor II Medium speed
N Neutral III Maximum speed
L Phase SDP Power chart
Com Common (white)
Remote control
230Vac/50Hz
Cross section area= 1,5 mm
2
Motor power supply
230Vac/50Hz
Com
I
II
III
LN PE
14 15 16 17
1234
SDP (power chart)
25 26 27 28
Com
III
II
I
Remote control
230Vac/50Hz
Cross section area= 1,5 mm
2
Com
I
II
III
Motor power supply
230Vac/50Hz
LN PE
14 15 16 17
1234
SDP (power chart)
25 26 27 28
blue
brown
grey
black
min med max Com
XA1
blue
brown
orange
black
greeen
yellow
FAN COIL
UTC
WIRING DIAGRAM UTC MOD. 50
WIRING DIAGRAM UTC MOD. 60
FAN MOTOR CABLE COLOURS
mot. EM mot. EL
Min.speed red blue
Med.speed blue black
Max speed black brown
Common white white
7
