TECHNICAL MANUAL
range
VERSIONE 1 - Horizontal ceiling models with cabinet (bottom air intake with socle)
N.B.: On the models VCE101, VCE111 and VCE121 the fold on the cabinet is not foreseen!
Dimensions Standard coil Auxiliary coilDistance
between slots
N.o
grilles
MOD. CODE H L S C D G N Y A B M X E F I O
VCE11 A0015090011 610 660 225 370 395 233 39 109 274 137 103 53 337 67 4 482
VCE21 A0015090021 610 860 225 570 595 233 39 109 274 137 103 53 337 67 6 482
VCE31 A0015090031 610 1.060 225 770 795 233 39 109 274 137 103 53 337 67 8 482
VCE41 A0015090041 610 1.060 225 770 795 233 39 109 274 137 103 53 337 67 8 482
VCE51 A0015090051 610 1.260 225 970 995 233 39 109 274 137 103 53 337 67 10 482
VCE61 A0015090061 610 1.260 225 970 995 233 39 109 274 137 103 53 337 67 10 482
VCE71 A0015090071 715 1.260 225 970 995 253 41 107 268 253 101 52 374 124 10 532
VCE81 A0015090081 715 1.460 225 1.170 1.195 253 41 107 268 253 101 52 374 124 12 532
VCE91 A0015090091 715 1.460 225 1.170 1.195 253 41 107 268 253 101 52 374 124 12 532
VCE101 A0015090101 735 1.661 257 1.335 1.362 - - - - - - - - - 14 552
VCE111 A0015090111 735 1.961 257 1.635 1.662 - - - - - - - - - 17 552
VCE121 A0015090121 735 1.961 257 1.635 1.662 - - - - - - - - - 17 552
Conden.
fitting
VCE 11-91
C
D
L
179
108
25
25
130
O
H
G122
H
A
B
E
F
M
X
N
Y
Ø 20
O
S
130
S
148
I
L
H
C
D
L
216
116
25
25
O
72
278 153
130
Ø 20
I
S
389
120
328
175
77
62
114
H
S
130
Ø 20
63
O
S
Ø 20
O
H
120
389
215
308
130
39
62
114
141
LEFT
VERSION
RIGHT
VERSION
236
236
VCE 101-121
