TECHNICAL MANUAL
range
OUTLET LOUVRES and INTAKE ABS GRILLE (with air filter)
In high-strength enamelled sheet metal, they are complete with fixed louvres in thermoplastic material for the distribution/intake of air
ALUMINIUM ADJUSTABLE SUPPLY AIR GRILL (without filter)
ALUMINIUM FIX INTAKE AIR GRILL WITH AIR FILTER
125
155
155
T1
L1
15
15
15
15
18
T1
18
L1 40
H1
H2
L2
L1
H1
H2
L2
MOD. CODE CODE L1 T1
mm mm
VCE10 A0055520000 A0055520025 300 330
VCE20 A0055520001 A0055520026 500 530
VCE30 A0055520002 A0055520027 700 730
VCE40 A0055520002 A0055520027 700 730
VCE50 A0055520003 A0055520028 900 930
VCE60 A0055520003 A0055520028 900 930
VCE70 A0055520003 A0055520028 900 930
VCE80 A0055520004 A0055520029 1.100 1.130
VCE90 A0055520004 A0055520029 1.100 1.130
VCE100 * ***
VCE110 * ***
VCE120 * ***
Outlet Inlet
VCE10 A0055520060 348 173 295 120
VCE20 A0055520061 548 173 495 120
VCE30 A0055520062 748 173 695 120
VCE40 A0055520062 748 173 695 120
VCE50 A0055520063 948 173 895 120
VCE60 A0055520063 948 173 895 120
VCE70 A0055520063 948 173 895 120
VCE80 A0055520064 1.148 173 1.095 120
VCE90 A0055520064 1.148 173 1.095 120
VCE100 A0055520065 1.376 173 1.320 120
VCE110 A0055520066 1.676 181 1.620 128
VCE120 A0055520066 1.676 181 1.620 128
MOD. CODE L1 H1 L2 H2
mm mm mm mm
VCE10 A0055520046 355 165 303 112
VCE20 A0055520047 555 165 503 112
VCE30 A0055520048 755 165 703 112
VCE40 A0055520048 755 165 703 112
VCE50 A0055520049 955 165 903 112
VCE60 A0055520049 955 165 903 112
VCE70 A0055520049 955 165 903 112
VCE80 A0055520050 1.155 165 1.103 112
VCE90 A0055520050 1.155 165 1.103 112
VCE100 A0055520051 1.374 179 1.322 126
VCE110 A0055520052 1.674 179 1.622 126
VCE120 A0055520052 1.674 179 1.622 126
MOD. CODE L1 H1 L2 H2
mm mm mm mm
ISO 9001:2000 - Cert. n. 1368/1
36
