FIGURE 8
HITCH ASSEMBLY PARTS
PARTS
E-16
HM600 HM720/HP720
REF. PART NO. PART NO. DESCRIPTION QTY.
1.....99.E0004 ......99.E0004........1/4-20 Wing Nut ..................1
2.....60.0665 .......60.0665 ........Outer Drive Pulley Shield .............1
3.....00.0102 .......00.0102 ........Pinching Hazard Decal ..............1
4.....62.0759 .......62.0773 ........LeftHitch Arm ................... 1
5.....97.0504 .......97.0504 ........5/16-18 x 1/2 Carriage Bolt ............2
6.....60.0663 .......60.0663 ........Inner Drive Pulley Shield..............1
7.....99.SF05 .......99.SF05 ........5/16-18 Flange Nut ................6
8.....83.H16S .......83.H16S ........1"Split Bushing .................. 2
9.....83.BK50H ......83.BK45H .......Inner Drive Pulley .................1
10....99.SF0508......99.SF0508 .......5/16-18 x 1 Flange Bolt ..............4
11....55.FB16016-1 ....55.FB16016-1 .....1"Flange Block Bearing ..............2
12....99.A08 ........99.A08 .........1/2-13 Locknut ................... 2
13....64.0680 .......64.0680 ........LiftArmBushing .................. 2
14....90.0818 .......90.0818 ........1/2-13 x 2-1/4 Bolt .................2
15....00.0101 .......00.0101 ........Moving Part Hazard Decal .............1
16....62.0760 .......62.0774 ........Right Hitch Arm ..................1
17....02.CP0512 .....02.CP0512.......5/32 x 1-1/2 Cotter Pin ...............1
18....95.08 ........95.08..........1/2SAEWasher ..................2
19....83.BK55H ......83.BK55H .......Outer Drive Pulley .................1
20....80.0291 .......80.0294 ........Drive Shaft ..................... 1
21....81.B045 .......81.B045 ........B45Belt ...................... 1
22....85.K0410 ......85.K0410........1/4x1-1/4 Key................... 2
23....90.0410 .......90.0410 ........1/4-20 x 1-1/4 Bolt .................1
24....99.SF04 .......99.SF04 ........1/4-20 Flange Nut .................2
