41 26404 WOODRUFF KEY - 1/4" x 1" (MODIFIED)
42 - -
43 - -
44 - -
45 - -
46 - -
47 - -
48 - -
49 - -
50 - -
51 22494 FIELD SERVICE LABEL KIT - HT40KX NON-PROP.
52 22494-1 FIELD SERVICE LABEL KIT - HT40KX PROPORTIONAL
53 22495 FIELD SERVICE LABEL KIT - HT50KX NON-PROP.
54 22495-1 FIELD SERVICE LABEL KIT - HT50KX PROPORTIONAL
55 - -
56 - -
57 - -
58 - -
59 - -
60 - -
61 - -
62 - -
63 - -
64 - -
65 - -
66 - -
67 - -
68 - -
69 - -
70 - -
71 - -
72 - -
73 - -
74 - -
75 - -
76 - -
77 - -
78 - -
79 - -
80 - -
22517
C400
10-29-01B
3-4-03C
REPLACEMENT PARTS
HT40KX, HT50KX
SUPERCEDES
TITLE
DATE
SECTION
1 22017 LOWER BEARING - 8" OD x 1.5" LONG
2 14084 COUPLING
3 14142-4 WORM - SINGLE THREAD RH
4 14159 SHIM - 1-1/2" SQ x .015", .042", .105"
5 14191-1 BALL THRUST BEARING - 2" ID x 3-11/32" OD
6 14191-2 BALL THRUST BEARING - 1-1/2" ID x 2-19/32" OD
7 14242 HOUSING, WORM GEAR
8 14245 WASHER PLATE
9 14341-1 BUSHING - 2.003" ID x 2.252" OD x 15/16" LONG
10 14341-2 BUSHING - 1.503" ID x 1.752" OD x 1" LONG
11 14344 SHIM WASHER - 1-1/2" ID x 2-1/8" OD x .005", .015", .031" THK
12 22468 HD STEEL FLANGE MOUNTED BALL BEARING - 1" BORE
13 14384 SPROCKET AND SHAFT ASSEMBLY (40T SPROCKET)
14 14481 ROTATION DRIVE CHAIN
15 15245 WOODRUFF KEY - 5/16" x 1-1/8" (MODIFIED)
16 17770 HEADACHE BALL ASSEMBLY
17 18068 BEARING HOUSING - 1-1/8" LONG
18 18069 FLANGED BEARING - 2" BORE x 3" OD FLANGE
19 22006 WELDED HOUSING ASSEMBLY
20 22021-1 ELEV. CYL. 4.5" BORE x 2" ROD x 19.63" STROKE
21 22022-1 ELEV. CYL. 5" BORE x 2" ROD x 19.63" STROKE
22 22024 STOP RING - ROTATION
23 22026 LOWER BEARING PLATE ASSEMBLY
24 22030 QUILL ASSEMBLY
25 22041 WORM GEAR - ROTATION
26 24524 BOOM ASSEMBLY - HT40/50KX
27 24550 FULL POWER BOOM ASSEMBLY - HT40/50KXX
28 22266 WINCH - 3000 LB (SINGLE LINE) - HT40KX
29 22268 WINCH - 4000 LB (SINGLE LINE) - HT50KX
30 22274 PIVOT PIN, CYL TAIL - 1-1/2" OD x 2-13/16" LONG
31 22275 PIVOT PIN, CYL ROD - 1-1/2" OD x 6-7/8" LONG
32 22290 PIVOT PIN, BOOM - 1-3/4" OD x 12-1/2" LONG
33 22291 SPROCKET AND SHAFT ASSEMBLY (10T SPROCKET)
34 22294 HYDRAULIC MOTOR - ROTATION
35 22298 LOWER COVER
36 22303 CHAIN COVER
37 22322 VALVE COVER ASSEMBLY
38 22387 RAIN COVER - QUILL
39 - -
40 17094-3/8-100 WIRE ROPE ASSEMBLY - 3/8" x 100 FT
ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION
REPLACEMENT PARTS DWG REF 22346
CINCINNATI, OHIO
MANUFACTURING, INC.
1
ITEM NOT SHOWN ON REPLACEMENT PARTS DRAWING
1
1
