Venturo HT40KX - HYDRAULIC COMPONENTS PARTS LIST

HT40
HT50
HYDRAULIC SYSTEM COMPONENTS - HT40/50KX CRANES
REPLACEMENT PARTS LIST
ITEM PART NUMBER DESCRIPTION
1 20685 PRESSURE HOSE - HOUSING SIDE
2 20686 RETURN HOSE - HOUSING SIDE
3 22501 VALVE BANK - HT40KX, HT50KX
4 22523 VALVE ASSEMBLY (VALVE BLOCK, VALVE, COIL, & HARDWARE)
22362 COIL ONLY
5 22363 EXTENSION CYLINDER HOSE
6 22505 HYD TUBING - ROTATION RIGHT
7 22506 HYD TUBING - ROTATION LEFT
8 22507 HYD TUBING - BOOM OUT
9 22508 HYD TUBING - BOOM IN
10 22509 HYD TUBING - BOOM UP
11 22510 HYD TUBING - BOOM DOWN
12 22511 HYD TUBING - PRESSURE
13 22512 HYD TUBING - RETURN
14 22513 HYD TUBING - WINCH UP
15 22514 HYD TUBING - WINCH DOWN
16 19247 COUNTERBALANCE VALVE (ELEVATION & EXTENSION CYLINDERS)
17 22382 ELEV CYLINDER HOSE - 22" x 6MBX x 6FJX
18 HBLK6MJ-6MJ HYD BULKHEAD
19 HBLK6MJ-6MJ-90 HYD BULKHEAD UNION ELBOW WITH LOCK NUT - 6MJ x 90°
20 HNPL6MJ-6MO HYD NIPPLE
21 HELB8MO-6MJ-90 HYD ELBOW
22 HNPL10MO-6MJ HYD NIPPLE
23 HRDB6MO-4FP HYDRAULIC BUSHING - 6MO-4FP
24 22502 PROPORTIONAL VALVE
25 22503 MASTER BYPASS VALVE AND COIL
26 22312-X.XX PRIORITY FLOW CART (X.XX REFER TO CHART BELOW)
27 20684 LIVE CONTINUOUS HYDRAULIC SWIVEL
28 20687 PRESSURE HOSE - COMPARTMENT SIDE
30 20688 RETURN HOSE - COMPARTMENT SIDE
TITLE SECTION
SUPERCEDES
DATE
20930
C400
-
10-10-02
REPL. PARTS LIST
HT40/50KX
CINCINNATI, OHIO
MFG., INC.
REPLACEMENT PARTS DWG REF 20699
SERIAL NO. 84030 & UP
SERIAL NO. 85030 & UP
STANDARD PROPORTIONAL
(NON-PROP)
EXTENSION 1.25 2.25
ELEVATION 1.75 4.00
EXTENSION 1.25 2.25
ELEVATION 2.25 4.00
