EC Declaration of Conformity
In accordance with EN 45014:1998
We, Veracity UK Ltd. of 6 Barns Street, Ayr, KA7 1XA
declare that the equipment “OUTREACH” Ethernet repeaters
model number VOR-ORM / VOR-ORL
conform to the essential protection requirements of the EMC Directive 89/336/EEC as amended.
The following EMC standards have been applied:
BS EN 55022:1998 Emissions (Class B Radiated)
BS EN 55024:1998 Immunity (BS EN 61000-4-2:1995 Immunity to ESD,
BS EN 61000-4-3:2000 Immunity to Radiated RF Fields (3V/m))
I hereby declare that the equipment named above has been been found to comply with the relevant sections
of the above referenced specifications. The unit complies with all essential requirements of the EMC Directive.
Responsible Person Mr Alastair McLeod, Director
Issued 9th October 2009 at Ayr
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Example OUTREACH MAX / OUTREACH LITE applications
1. Delivering 20 watts to a PoE Plus device over 300 metres (984 feet)
More tha n one OUTREACH Max ma y be connected i n s eri es to e xtend PoE a nd Ethernet for s evera l hundred metres . In the example a bove,
Veracity's OUTSOURCE PLUS i njector i s used to a dd enhanced PoE Plus ca pa bi l i ty to a regul a r unpowered network port.
Two OUTREACH MAX units are l oca ted 100 metres a nd 200 metres from the s wi tch, a l l owing a PoE Plus wirel es s acces s poi nt to be i ns ta lled
up to 300 metres from the powe r s ource.
2. Extending an unpowered network connection to 200 metres (656 feet)
The combina ti on of Veraci ty's OUTSOURCE e nhanced PoE i njector a nd OUTREACH LITE Ethernet range extender del i vers a s i mple a nd rel i a bl e
mea ns to extend LAN cabl i ng beyond i ts 100 metre limi t.
By connecti ng a s i ngl e OUTREACH LITE a fter 100 metres of ca bli ng, the connection from network s wi tch port to wa l l outlet ma y extend up to
200 metres. OUTSOURCE del ivers power to the OUTREACH LITE, a nd may be convenientl y l ocated nea r the network s witch.
3. Combining OUTREACH LITE and OUTREACH MAX to deliver an unrestricted network connection beyond 200 metres
For extendi ng data-only connecti ons, where no PoE i s requi red for the end de vice, a combi na tion of OUTREACH MAX and OUTREACH LITE ma y
be us ed to i ncreas e range beyond 200 me tres . The OUTREACH MAXes forwa rd both data a nd PoE from the PoE s wi tch to the powe red device,
which i n this cas e i s the OUTREACH LITE. The tota l di s ta nce from s witch to outlet i n the exampl e i s up to 400 metres (1316 feet).
Unres tricted 100Ba s e-T ful l-dupl ex (tota l ba ndwidth 200Mbi t/s ) conne cti ons of up to 2200 metres (7218 fee t) between power s ources a re
pos si ble us ing thi s method.
4. Versatile network expansion with distributed PoE using OUTREACH QUAD
In thi s exa mpl e an OUTREACH MAX is us ed to forwa rd enhanced PoE Plus power to a n OUTREACH QUAD PoE-forwa rding s wi tch, locate d up to
200 metres from the network s witch a nd OUTSOURCE PLUS i njector.
The OUTREACH QUAD extends the PoE a nd network connecti on a furthe r 200 metres to a n IP camera us i ng OUTREACH MAX, a nd provides a
PoE network port for a VoIP phone, pl us a n a dditi onal two network connecti ons for other devices or for connection to a loca l network.
