Verathon BLADDERSCAN PRIME Service Manual

ii
SETTING UP................................................................................................................................................................16
16
Procedure 1. Perform the Initial Inspection .....................................................................................................16
Procedure 2. Charge the Battery ....................................................................................................................17
Procedure 3. Attach the Probe to the Console ...............................................................................................19
Procedure 4. Attach the Console Base or Printer ...........................................................................................20
Procedure 5. Attach the Instrument to the Mobile Cart (Optional) .................................................................21
Procedure 6. Install the Port Cover (Optional) ................................................................................................ 24
Procedure 7. Insert a Battery ..........................................................................................................................25

Procedure 1. Congure General Settings .......................................................................................................26
Procedure 2. Congure Exam Settings ..........................................................................................................28
Procedure 3. Customize Cost Savings Calculations ......................................................................................29
Procedure 4. Congure Printed Report Settings ............................................................................................31
Procedure 5. Congure Calibration Settings ..................................................................................................32
USING THE INSTRUMENT ....................................................................................................................................... 33

Procedure 1. Start the System ........................................................................................................................34
Procedure 2. Prepare for the Exam ................................................................................................................35
Procedure 3. Input Patient Information or Operator ID (Optional)..................................................................36
Procedure 4. Measure Bladder Volume ..........................................................................................................37
Procedure 5. Review Exam Results ...............................................................................................................41
Procedure 6. Print, Save, or Exit an Exam .....................................................................................................43
Procedure 7. View Cost Savings.....................................................................................................................44
45
Procedure 1. Recall a Saved Exam ................................................................................................................45
Procedure 2. Delete a Saved Exam ...............................................................................................................46
Procedure 3. Export Saved Exams .................................................................................................................47
CLEANING & DISINFECTING ..................................................................................................................................48
Procedure 1. Clean & Disinfect the System ....................................................................................................50

Verathon BLADDERSCAN PRIME Specifications

General

Manufacturer	Verathon
Model	BLADDERSCAN PRIME
Category	Medical Equipment
Application	Bladder volume measurement
Technology	Ultrasound
Portability	Portable
Volume range	0-999 mL
Battery	Rechargeable lithium-ion
Connectivity	USB
Display	Touchscreen LCD
Intended Use	Non-invasive measurement of urinary bladder volume
Accuracy	± 15% or ± 15 mL, whichever is greater
