8
BULB REPLACEMENT INSTRUCTIONS
Removal
1. Unplug lamp from power source.
2. To access to the bulb, remove grid
diffuser by depressing the tab and
lifting it out. (See page 7)
3. Firmly hold bulb base (B) and pull
bulb (C) from the socket (A) in
an outward motion.
Installation
1. Unplug lamp from power source.
2. Firmly hold base (B) and push bulb
(C) into the socket (A).
3. Be sure bulb is fi rmly seated in the
socket (see below) and snapped
into the metal bulb clip (D).
4. Replace grid diffuser.
No
gap
Notice
large gap
Correctly seated bulb Incorrectly seated bulb
YES NO
Fig. 10
C
B
A
C
B
A
