Table 2-6
Summary of supported NetBackup 5240 FC options (continued)
Supported options and required port configurationFC HBA slot
Port 1
■ Optimized duplication - initiator or target (5230 only)
■ Auto Image Replication - initiator or target (5230 only)
■ Tape out - initiator
■ NetBackup for VMware - initiator
Port 2
■ Optimized duplication - initiator or target
■ Auto Image Replication - initiator or target
■ Tape out - initiator
■ NetBackup for VMware - initiator
Use only one option on each port.
This slot is populated with an FC card on 5240 HBA configurations D,
E, and K.
Slot 4
Port 1
■ SAN Client - target
■ Tape out - initiator
■ NetBackup for VMware - initiator
Port 2
■ SAN Client - target
Note: If Port 1 is in the initiator mode, Port 2 cannot be set to the
target mode. Port 2 can only be configured for the target mode when
the 4 target port Fibre Channel connection option is selected.
■ Optimized duplication - initiator
■ Auto Image Replication - initiator
■ Tape out - initiator
■ NetBackup for VMware - initiator
Use only one option on each port.
This slot is populated with an FC card on 5240 HBA configurations D,
E, H, and K.
This slot is reserved for Fibre Transport media server (FTMS) on 5240
HBA configurations D, E, H, and K. If you enable SAN Client FTMS
with those two configurations, Port 1 is changed to target mode for SAN
Client by default.
Slot 5
45About the HBA port mode configuration
Supported Fibre Channel port configuration for the NetBackup 5240 appliances
