3
Components
➊ Status LED indicator — indicates the network and trac status; it also indicates when there
is no SIM or a SIM error, and when a software update is in progress. (See Package Contents
on page 2.)
➋ Data Used LED indicator — indicates data usage from less than 80% to 100% or greater; it
also indicates when data usage information is not available.
➌ USB Connector — connects to your computer through a type A USB port.
➍ USB Connector Pivot— allows the USB Connector to rotate, making it easier to connect to
computers.
➎ USB Folding Hinge — folds the USB Connector into your MiFi U620L Modem, and allows the
USB Connector to be extended and plugged into your computer. (See Properly Insert the
Device in Your Computer on page 8.)
➏ Back Panel (removable) — covers the 4G LTE SIM card slot. Press gently on the cover with
your thumb and slide the panel o. The manual reset button can be found under this panel.
➐ 4G LTE SIM Card Slot — inside under the back panel, insert the 4G LTE SIM card into the
spring-loaded SIM card slot (under the back panel - not shown). (See Install the 4G LTE SIM
Card on page 8.)
2
1
3
4
5
6
7
(inside under cover)
