Introduction
AC12 Technical Specifications
Power Consumption 60W maximum
Power Input
IEEE 802.3af/at/bt PoE, PoE+, PoE++ (37VDC — 57VDC), 600mA maximum
per pair; 12VDC with 2.5A minimum current
Inputs
2x REX dry inputs
1x DPI dry input
1x AUX dry input
Readers
2x 12VDC @ 250mA reader ports (Verkada/RS-485 or Wiegand)
Note: Each of the 2 reader ports can power a maximum of 1 reader with
current consumption of at most 250mA.
PoE Output IEEE 802.3af/at PoE, PoE+ (37VDC–57VDC), 600mA maximum
Relay Outputs
1x wet relay for door with switch-selectable power:
● 12VDC operation @ 700mA maximum
● 24VDC operation @ 350mA maximum
● Dry operation
1x dry relay for auxiliary output with maximum pass-through power of
24VDC @ 2A (resistive load)
DC Power Output 1x 12VDC @ 100mA maximum
Dimensions 175.5 x 175.4 x 55.3 mm (6.91 x 6.91 x 2.18 in)
Weight 2.87 lb (1.30 kg)
Tamper Detection Yes
Operating Temperature 0 °C-50°C, 5-85% humidity
Compliance
FCC Part 15B Class B, ICES-003 Class B, CE, UKCA, VCCI, RCM, UL 294,
CAN-ULC 60839-11-1, UL 62368-1, and CSA C22.2 No. 62368-1, IK06,
Compliant with Requirements of UL2043, Indoor Use Only, to be used in
controlled, protected, and/or restricted access areas.
Installation and operation of the electronic access control system (EACS)
shall not prevent the functionality of the emergency exit functions.
Connectivity
Ethernet: 10/100/1000 Mbps RJ-45 for network connection
USB 2.0
Included Accessories T10 Security Torx screwdriver, mounting hardware kit
Mounting Options Wall, Ceiling, or Plenum Mount
Verkada Inc. 406 E 3rd Ave, San Mateo, CA 94401
sales@verkada.com
All specifications are subject to change without notice
Copyright © 2023 Verkada Inc. All rights reserved.
