Model E3 Bolted Metallic • 16
ww w.ve rsam atic .com
UNIT PARTS BEING REMOVED
Item # Part Number Description Qty.
15
"196.V008.156
196.V008.110
196.V008.332
196.V008.309"
"AIR CHAMBER (ALUMINUM)
AIR CHAMBER (STAINLESS)
AIR CHAMBER (NICKEL PLATED)
AIR CHAMBER (PTFE COATED)"
2
18 755.V002.000 PILOT SLEEVE 1
20 675.037.080 RETAINING RING 1
21 775.V006.000 PILOT SPOOL 1
SUPPLEMENT SHEET FOR
SERVICE MANUAL - e3mdlCsmATEXMB
PUMP MODEL - 3" Elima-Matic Bolted Metallic with Metallic Center Section
PARTS BEING REPLACED WITH
Item # Part Number Description Qty.
"P34-111
SP34-111
P34-111NP
P34-111TC"
"AIR CHAMBER (ALUMINUM)
AIR CHAMBER (STAINLESS)
AIR CHAMBER (NICKEL PLATED)
AIR CHAMBER (PTFE COATED)"
2
P24-106 PILOT VALVE RING 5
P24-107 PILOT VALVE O-RING 6
P24-108 JAM NUT 2
P34-104 PILOT SHAFT 1
"P34-105
SP34-105"
"THREADED BUSHING (BRASS)
THREADED BUSHING (STAINLESS)"
2
