Versa-Matic E3 - Dimensional Drawings

e3mdlHsmATEXMB-rev0317
Model E3 Bolted Metallic • 4
ww w.ve rsam atic .com
E3 Bolted Metallic
Dimensions in inches (metric dimensions in brackets). Dimensional Tolerance .125" (3mm).
Dimensional Drawings
4.44
113
32.32
821
24.94
634
14.92
379
22.06
560
4X .50
13
SUCTION PORT
3" 150# ANSI / DIN FLANGE
SUCTION PORT
3" 150# ANSI / DIN FLANGE
AIR EXHAUST
1" NPT
2X 3.50
89
36.26
921
16.21
412
14.13
359
11.00
279
9.50
241
2.88
73
17.00
432
4X .60
15
1/2" NPT
3/4" NPT Stainless Steel Centers ONLY
AIR INLET
4.44
113
32.32
821
24.94
634
14.92
379
22.06
560
4X .50
13
SUCTION PORT
3" 150# ANSI / DIN FLANGE
SUCTION PORT
3" 150# ANSI / DIN FLANGE
AIR EXHAUST
1" NPT
2X 3.50
89
36.26
921
16.21
412
14.13
359
11.00
279
9.50
241
2.88
73
17.00
432
4X .60
15
1/2" NPT
3/4" NPT Stainless Steel Centers ONLY
AIR INLET
1: PUMP SPECS
