Versa-Matic E5 - E5 1;2 Bolted Metallic Pump Specifications and Performance

Versa-Matic
®
E5 1/2" Bolted Metallic OM
SPECIFICATIONS AND PERFORMANCE
Versa-Matic Model
E5 1/2" Bolted Metallic Pump
Flow Rate
Adjustable to . . . . . . . . 0-14 gpm (56 lpm)
Port Size
Suction . . . . . . . . . . . . . . . . . . .50" NPTF
Discharge . . . . . . . . . . . . . . . . .50" NPTF
Air Inlet . . . . . . . . . . . . . . . . . 0.375" NPT
Air Exhaust . . . . . . . . . . . . . 0.375" NPT
Suction Lift
Rubber . . . . . . . . . . . . . . 20' (6.09 m) Dry
Teflon . . . . . . . . . . . . . . . . 5' (1.52 m) Dry
Max. Particle Size (Diameter)
. . . . . . . . . . . . . . . . . . 0.0625" (1.66 mm)
dB(A) Reading . . . . . . . . . . . . 67.1 dB(A)
Shipping Weights
Aluminum. . . . . . . . . . . . . . 18 lbs (4.5 kg)
Stainless Steel . . . . . . . . . . 15 lbs (4.5 kg)
Hastelloy C . . . . . . . . . . . . 10 lbs (4.5 kg)
Caution: do not exceed 125 psig
(8.5 bar) liquid or air supply pressure.
Meters Feet
Discharge Head in PSI
2106
0
100
90
80
70
60
50
40
30
20
10
0
240
220
200
180
160
140
120
100
80
60
40
20
0
75
70
65
60
55
50
45
40
35
30
25
20
15
10
5
0
128414
40
0
5101520253035 455055
Capcity in Liters Per Minute
Capcity in U.S. Gallons Per Minute
Displacement Per Stroke, 0.03 Gal. (0.11 L)
4
8
12
16
2
AIR CONSUMPTION IN SCFM
AIR PRESSURE IN PSI
SCFM M
3
/HR
2 3.4
4 6.8
8 13.6
12 20.4
16 27.2
6.25
[15.9]
7.36 18.7
9.87
[25.1]
9.35
[23.7]
5.98
[15.2]
.95
[2.4]
7.39
18.8
3/8" NPT Air Inlet
3/8" NPT Air Exhaust
1/2"NPT Inlet
1/2" NPT Discharge
5.26
[13.4]
4.38
[11.1]
4.00
[10.2]
1.13
[2.9]
3.25
[8.3]
Inches [mm]
E5 1/2" Bolted Metallic Pump
