Vertex Standard MH-67A8J User Manual

5
Printed Circuit Board AAE60X000 FR019050A 1-20
FR019050B 21-27
FR019050C 28-
C 1001 CHIP CAP. 1uF 25V B C2012JB1E105KT K22140825 1- B
C 1002 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B
C 1003 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B
C 1004 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 1- B
C 1004 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B
C 1005 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B
C 1006 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B
C 1007 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B
R 1001 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- B
R 1002 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B
R 1003 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B
R 1003 CHIP RES. 5.6k 1/16W 5% RMC1/16 562JATP J24185562 1- B
R 1004 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B
R 1004 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B
S 1001 TACT SWITCH SKHHLVA010 N5090161 1- A
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAY ADR

Vertex Standard MH-67A8J Specifications

General

Brand	Vertex Standard
Model	MH-67A8J
Category	Microphone
Language	English
