Vertex Standard VX-231 - REPEATERS

Specications are subject to change without notice or obligation.
22
Specications
VXR-1000 VXR-7000 VXR-9000
GENERAL
Frequency Range
VHF: 150 – 174 MHz
UHF: 450 – 470 MHz
VHF: 134 – 150 MHz; 150 – 174 MHz
UHF: 400 – 430 MHz; 450 – 480 MHz
VHF: 134 – 160 MHz; 148 – 174 MHz
UHF: 400 – 430 MHz; 450 – 490 MHz
Channels 16 16 32
Power Supply Voltage 13.8 V DC 115 / 230 V AC ±10% 50/60 Hz or 13.8 V DC 13.6 V DC ± 10%
Channel Spacing
VHF: 15 / 30 kHz
UHF: 12.5 / 35 KHz
12.5 / 20 / 25 kHz 12.5 / 20 / 25 kHz
Operating Temperature Range -22º F to +140º F (-30º C to +60º C) -22º F to +140º F (-30º C to +60º C) -22º F to +140º F (-30º C to +60º C)
Frequency Stability ±2.5 ppm ±2.5 ppm 1.5 ppm, 1.0 ppm (30 min. after wake up)
RF Input-Output Impedance 50 Ohms 50 Ohms 50 Ohms
Dimensions (W x H x D)
4.4 x 1.0 x 5.4 inches
(111 x 25.4 x 136 mm)
12.8 x 4.5 x 15.4 inches
(325 x 115 x 391.5 mm)
19 x 3.5 x 13.5 inches
(483 x 88 x 343 mm)
Weight (Approx.) 14.1 oz (400 g) 22 lbs (10 kg) 21.4 lbs (9.7 kg) (50W model)
RECEIVER
Sensitivity 12dB SINAD
VHF: 0.30 μV
UHF: 0.35 μV
0.35 μV
VHF: 0.25 μV
UHF: 0.3 μV
AdjacentChannelSelectivity – 80 dB / 74 dB
VHF: 85 dB / 79 dB
UHF: 84 dB / 77 dB
Intermodulation 60 dB 75 dB
VHF: 83 dB / 81 dB
UHF: 82 dB / 80 dB
SpuriousandImageRejection 60 dB 90 dB 90 dB
Audio Output 1 W @ 8 Ohms 4 W @ 4 Ohms 4 W @ 4 Ohms
TRANSMITTER
Output Power 5/2.5/1/0.5 W 10to50W(adjustable) 50 / 25 / 10 W (100 W optional)
Duty Cycle – 100% 50%
Modulation 16K0F3E, 11K0F3E 16K0F3E, 11K0F3E 16K0F3E, 11K0F3E
Maximum Deviation ±5.0 kHz / ±2.5 kHz ±5.0 kHz / ±2.5 kHz ±5.0 kHz / ±2.5 kHz
Audio Distortion < 5% @ 1 kHz < 2.5% @ 1kHz < 2.5% @ 1kHz
Conducted Spurious Emmission 60 dB below carrier Better than 75 dB below carrier 80 dB below carrier
REPEATERS
Find more useful tools and information
online in our resource center.
• Owners Manuals
• Spec Sheets
• Brochures
• Fact Sheets
• Videos
• FCC Narrowbanding
www.vertexstandard.com/lmr
