Specications
VX-P820 SERIES VX-P920 SERIES VX-7200
GENERAL
Frequency Range
VHF: 134 – 174 MHz
UHF: 380 – 450 MHz, 400 – 470 MHz,
450 – 512 MHz
VHF: 134 – 174 MHz
UHF: 380 – 450 MHz, 400 – 470 MHz,
450 – 512 MHz
VHF: 134 – 174 MHz
UHF: 380 – 450 MHz, 400 – 470 MHz,
450 – 512 MHz
Channels
512 (VX-P829, VX-P824)
16 (VX-P821)
512 501
Power Supply Voltage 7.4 V DC ± 20% 7.4 V DC ± 20% 13.6 V DC ± 15%
Channel Spacing 12.5 / 20 / 25 kHz 12.5 / 20 / 25 kHz 12.5 / 20 / 25 kHz
PLL Steps
VHF: 1.25/2.5 / 5 / 6.25 kHz
UHF: 5 / 6.25 kHz
VHF: 1.25/2.5 / 5 / 6.25 kHz
UHF: 5 / 6.25 kHz
VHF: 1.25/2.5 / 5 / 6.25 kHz
UHF: 5 / 6.25 kHz
Battery
3000 mAh Li-Ion (IS option)
2000 mAh Li-Ion
1150 mAh Li-Ion
3000 mAh Li-Ion (IS option)
2000 mAh Li-Ion
1150 mAh Li-Ion
–
Battery Life
5-5-90 duty with saver
FNB-V92LI
FNB-V87LI
FNB-V86LI
21 hrs
14 hrs
9.5 hrs
21 hrs
14 hrs
9.5 hrs
–
Current Consumption – – TX: 11 A, RX: 2.5 A, Standby: 0.4 A
IP Rating IP 57 IP 57 –
Operating Temperature Range
-22º F to +140º F
(-30º C to +60º C)
-22º F to +140º F
(-30º C to +60º C)
-22º F to +140º F
(-30º C to +60º C)
Frequency Stability ±2.5 ppm ±2.5 ppm ±2.5 ppm
Dimension (H x W x D)
3.8 x 2.3 x 1.5 inches
(96.5 x 57.5 x 37.5 mm) (w/FNB-V86LI)
5.3 x 2.3 x 1.5 inches
(133 x 57.5 x 37.5 mm) (w/FNB-V86LI)
6.5 x 1.7 x 6.1 inches
(165 x 43 x 155 mm)
Weight (Approx.)
10.9 oz (310 g)
(w/FNB-V86LI, Belt Clip)
13.4 oz (380 g)
(w/FNB-V86LI, Belt Clip)
3.1 lbs (1.4 kg)
RECEIVER
Sensitivity
12 dB SINAD: 0.25 μV (VHF); 0.32 μV (UHF)
Digital 5% BER: 0.25 μV (VHF); 0.32 μV (UHF)
Digital 1% VER: 0.35 μV (VHF); 0.40 μV (UHF)
12 dB SINAD: 0.25 μV (VHF); 0.32 μV (UHF)
Digital 5% BER: 0.25 μV (VHF); 0.32 μV (UHF)
Digital 1% VER: 0.35 μV (VHF); 0.40 μV (UHF)
12 dB SINAD: 0.25 μV (VHF); 0.32 μV (UHF)
Digital 5% BER: 0.25 μV (VHF); 0.32 μV (UHF)
Digital 1% VER: 0.35 μV (VHF); 0.40 μV (UHF)
AdjacentChannelSelectivity(W/N) 75 / 70 dB 75 / 70 dB 80/ 75 dB (VHF), 80 / 72 dB (UHF)
Intermodulation 75 / 70 dB 75 / 70 dB 80 dB
Hum and Noise 48 / 42 dB 48 / 42 dB –
SpuriousandImageRejection 80 dB (VHF); 75 dB (UHF) 80 dB (VHF); 75 dB (UHF) 90 dB (VHF), 85 dB (UHF)
Audio Output 700 mW @ 16 Ohms 5% THD 700 mW @ 16 Ohms 5% THD
Internal: 2 W @ 32 Ohms, 5% THD
External: 12 W @ 4 Ohms, 5% THD
TRANSMITTER
Output Power 5 / 2.5 / 1 / 0.25 W 5 / 2.5 / 1 / 0.25 W
VHF: 50 / 25 / 10 W
UHF: 45 / 25 / 10 W
Modulation
Analog: 16K0F3E, 11K0F3E
Digital: 8K10F1D / 8K10F1E
Analog: 16K0F3E, 11K0F3E
Digital: 8K10F1D / 8K10F1E
Analog: 16K0F3E, 11K0F3E
Digital: 8K10F1D / 8K10F1E
Spurious Emission 70 dB 70 dB 70 dB
FM Hum and Noise (W/N) 46 / 40 dB 46 / 40 dB 46 / 40 dB
Audio Distortion <3% @ 1 kHz <3% @ 1 kHz <3% @ 1 kHz
