Specications
VXD-720 PORTABLE VXD-7200 MOBILE VXD-R70 REPEATER
GENERAL
Frequency Range
VHF: 136 – 174 MHz
UHF: 403 – 470 MHz, 450 – 512 MHz
VHF: 136 – 174 MHz
UHF: 403 – 470 MHz, 450 – 512 MHz
VHF: 136 – 174 MHz
UHF: 403 – 470 MHz, 450 – 512 MHz
Channels 512 512 16
Power Supply Voltage 7.5 V nominal 13.6 V DC ±20% 100 – 240 V AC (13.6 V DC)
Channel Spacing 12.5 / 25 kHz 12.5 / 25 kHz 12.5 / 25 kHz
Battery
2200 mAh Li-Ion
1300 mAh Ni-MH
– –
Battery Life
5-5-90 duty with battery saver
FNB-V117LI
FNB-V116
19 hrs (digital) / 13.5 hrs (analog)
11 hrs (digital) / 8 hrs (analog)
– –
Current Consumption –
TX @ 1-25 W: 11.0 A max
TX @ 25 – 40 W: 14.5 A max
RX: 2 A max, Standby: 0.81 A max
Standby: 1 A (1 A DC typical)
TX Low Power: 3 A (7.5 A DC typical)
TX High Power: 4 A (12 A DC typical)
IP Rating IP 57 – –
Operating Temperature Range -22º F to +140º F (-30º C to +60º C) -22º F to +140º F (-30º C to +60º C) -22º F to +140º F (-30º C to +60º C)
Frequency Stability ±0.5 ppm ±0.5 ppm ±0.5 ppm
Duty Cycle – – 100%
Dimension (H x W x D)
5.18 x 2.5 x 1.39 inches
(131.5 x 63.5 x 36.2 mm) (w/FNB-V117LI)
2.01 x 6.89 x 8.11 inches
(51 x 175 x 206 mm)
5.22 x 19 x 11.67 inches
(132.6 x 482.6 x 296.5 mm)
Weight (Approx.)
13.17 oz (375 g) (w/FNB-V117LI)
15.2 oz (430 g) (w/FNB-V-116)
4.0 lbs
1.8 kg
31 lbs
14 kg
RECEIVER
Sensitivity
Analog 12 dB SINAD: 0.35 μV 0.22 μV typical
Digital: 5% BER: 0.3 μV
Analog 12 dB SINAD: 0.35 μV 0.22 μV typical
Digital: 5% BER: 0.3 μV
Analog 12 dB SINAD: 0.35 μV 0.22 μV typical
Digital: 5% BER: 0.3 μV
AdjacentChannelSelectivity
TIA603: 60 dB @ 12.5 kHz, 70 dB @ 25 kHz
TIA603C: 45 dB @ 12.5 kHz, 70 dB @ 25 kHz
TIA603 VHF: 65 dB @ 12.5 kHz, 80 dB @ 25 kHz
TIA603 UHF: 65 db @ 12.5 kHz, 75 dB @ 25 kHz
TIA603C VHF: 50 dB @ 12.5 kHz, 80 dB @ 25 kHz
TIA603C UHF: 50 dB @ 12.5 kHz, 75 dB @ 25 kHz
Intermodulation 70 dB VHF: 78 dB, UHF: 75 dB VHF: 78 dB, UHF: 75 dB
SpuriousRejection 70 dB VHF: 80 dB, UHF: 75 dB VHF: 80 dB, UHF: 75 dB
Audio Output 500 mW
3 W (Internal), 7.5 W (External @ 8 Ohms)
13 W (External @ 4 Ohms)
–
Audio Distortion – 3% Typical 3% Typical
Hum and Noise -40 dB @ 12.5 kHz; -45 dB @ 25 kHz -40 dB @ 12.5 kHz; -45 dB @ 25 kHz -40 dB @ 12.5 kHz; -45 dB @ 25 kHz
Conducted Spurious Emission -57 dBm -57 dBm -57 dBm
TRANSMITTER
Output Power
VHF: 5 W / 1 W;
UHF: 4 W / 1 W
VHF: 1 – 25 W, 25 – 45 W
UHF (403 – 470 MHz): 1 – 25 W, 25 – 40 W
UHF (450 – 512 MHz): 1 – 40 W
VHF: 1 – 25 W, 25 – 45 W
UHF (403 – 470 MHz): 1 – 25 W, 25 – 40 W
UHF (450 – 512 MHz): 1 – 40 W
Modulation Limiting
±2.5 kHz @ 12.5 kHz
±5.0 kHz @ 25 kHz
±2.5 kHz @ 12.5 kHz
±5.0 kHz @ 25 kHz
±2.5 kHz @ 12.5 kHz
±5.0 kHz @ 25 kHz
Conducted/Radiated Emission -36 dBm < 1 GHz; -30 dBm > 1 GHz -36 dBm < 1 GHz; -30 dBm > 1 GHz -36 dBm < 1 GHz; -30 dBm > 1 GHz
FM Hum and Noise -40 dB @ 12.5 kHz; -45 dB @ 25 kHz -40 dB @ 12.5 kHz; -45 dB @ 25 kHz -40 dB @ 12.5 kHz; -45 dB @ 25 kHz
AdjacentChannelPower – 60 dB @ 12.5 kHz; 70 dB @ 25 kHz 60 dB @ 12.5 kHz; 70 dB @ 25 kHz
Audio Distortion 3% 3% 3%
FM Modulation 11K0F3E; 16K0F3E 11K0F3E; 16K0F3E 11K0F3E; 16K0F3E
4FSK Digital Modulation
12.5 kHz Data Only: 7K60FXD
12.5 kHz Data & Voice: 7K60FXE
12.5 kHz Data Only: 7K60FXD
12.5 kHz Data & Voice: 7K60FXE
12.5 kHz Data Only: 7K60FXD
12.5 kHz Data & Voice: 7K60FXE
Digital Protocol ETSI TS 102 361-1,-2,-3 ETSI TS 102 361-1,-2,-3 ETSI TS 102 361-1,-2,-3
