Your DeltaQuad Pro #VIEW is equipped with a Nighthawk2 camera system combined with a board
computer that controls the camera. The radio system on your vehicle is based on the Microhard Digital Data
Link. Your ground antenna is either an omnidirectional 1.5m antenna on a tripod, or a directional panel
antenna on an automatic antenna tracker.
Setting up and Connecting to your UAV
Your UAV comes with 2 ground stations. The Video Control Station (VCS) is a laptop computer with touch
screen capabilities. The Ground Control Station (GCS) is a hand-held tablet device. The VCS and GCS are
separated so that the pilot functions and camera operator functions can be performed separately.
Never press the deploy camera button while the UAV is on the ground. This may damage your
camera.
Using the omnidirectional antenna setup
There are 3 wires coming from the antenna tripod:
1. The power plug should connect to the supplied power bank.
2. The USB plug should be connected to the GCS tablet
3. The ethernet cable should be inserted into the VCS laptop
The supplied joystick should be attached to the VCS. After this, you can power on all devices including the
power bank and the UAV. The system will automatically connect to the UAV within 60 seconds.
