Vertiv™ Avocent® ACS800/8000 Advanced Console System Installer/User Guide
Appendices
Appendix A: Technical Specifications
Table A.1
Technical Specifications for the ACS8000 Advanced Console System Hardware
Appendices
Proprietary and Confidential ©2024 Vertiv Group Corp.
84
Category Value
General Information
CPU Dual Core ARM Cortex-A9 @ 766MHz
Memory 1GB DDR3L / 16GB eMMC F
LASH
Interfaces
• Two dual media 1000Base-TX Copper/1Gbps SFP Fiber ports
• Up to 48 serial ports with autosensing and switching support of Cyclades and Cisco pinouts
• Two of the serial ports support RS232/422/485 multi-protocol with autosensing and switching support of Cyclades and Cisco
pinouts in RS232 mode
• One serial console port
• Eight USB 2.0 host ports (front ports not available on some models)
• One SD card slot (not available on some models)
• Optional V.92/56K analog MODEM port or Cellular MODEM
• 1-Wire interface for external sensors (not available on some models)
• Single RJ45 connector with four digital-in ports for external contact closure sensors (not available on some models)
Power Information
Power S
upply Internal 100-240 VAC, 50/60 Hz Optional Dua
l entry, redundant power supplies-48 VDC option available
Power Consumption
Nominal voltage 120 VAC: Typical 0.17A, 20W, Maximum 0.25A, 30W
Nominal voltage 230 VAC: Typical 0.1 A, 23 W, Maximum 0.15A, 35W
Nominal voltage -48 VDC (20% tolerance) Typical 0.5 A
Ambient Atmospheric Condition Ratings
Operati
ng
Temperature
32
°
F to 122°F (0
°
C to 50
°
C) (DC powered units)
14°F to 158°F (-10° C to 70°C) (AC powered units)
Storage
Temperature
-4°F
to 158°F (-20°C to 70°C)
Humidity 20% to 80% relative humidity (non-condensing) across the operating temperature range
Dimensions
Height x Width x
De
pth
1.7 x 17.1 x 9.5 in (4.
318 x 43.434 x 24.13 cm)
Weight 6-7 pounds (2.722- 3.175 kg) depending on the model
