Installation, Operation and Maintenance Manual
®
EVC Heat Recovery Unit
Nomenclature
Part Number Coding
Point Description Point Variants Details (as appropriate)
1 Product EV Ecovent® Acoustic Heat Recovery Units
2 Heat Recovery type C Counterflow plate heat exchanger
3 Unit Size 0...5 Sequential see unit outline for details
4 Fan Type 4...7 Centrifugal EC fan
5 Fan Size 2...7 Sequential
6 Phase -1 230V 50Hz Single Phase
-3 400V 50Hz Three Phase
7 Unit Configuration /FP Flat Plantroom
/SP Stacked Plantroom
8 Main Heating Null No Heating
-E Electric Heater Battery
-W LPHW Coil
9 Infill /DS 25mm double skinned
/EE 50mm double skinned
10 Handing /LT Left/Top Access
(denotes position of /RT Right/Top Access
supply airflow LIDSAF) /LB Left/Bottom Access
/RB Right/Bottom Access
/L Left (stacked)
/R Right (stacked)
11 Main Filter Null No filter
/G4 EU4 Pleated Filter
/F7 High efficiency pleated filter
12 Control Panel Section /CPSC Fitted control panel
/ISC Fitted isolator/speed controller
13 Colour Null Galvanised finish
/R7004 Powdercoated finish, RAL7004 etc...
14 Powder Coat Type Null As colour
/IT Internal powdercoated only
/BT Internal/External powdercoated
15 Special /S Special (non-standard) Unit
EVC152-1/FP-W/EE/RT/G4/CPSC/S
EV C 1 5 2 -1 /FP -W /EE /RT /G4 /CPSC /S
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Typical Example
