VES ecovent EVC - Fan Specifications and Wiring Arrangements

9
ORIGINAL INSTRUCTIONSVES Andover Ltd Eagle Close Chandlers Ford Ind. Est Eastleigh Hampshire SO53 4NF
Tel: 08448 156060 Fax: 02380 261204 E-mail: vesltd@ves.co.uk Web: www.ves.co.uk
Installation, Operation and Maintenance Manual
®
EVC Heat Recovery Unit
Standard Fan Details
Fig.
16
Standard Wiring
& Fan Installation
5 Continued
90
1
0
5
1
2
0
6
0
75
90
1
0
5
1
2
0
45
30
1
BK
2
RD
3
WH
–
+
T ~
L
R
CM24-SR/NM24 Damper Actuator
To isolate from the main power supply, the system must incorporate a device which
disconnects all the phase conductors
Warning
Standard wiring
arrangement
Damper Motor Terminals
Fig.
17
AC 24 V 50Hz / DC 24 V
Size Phase
Motor
Size
Voltage
Fan
(rpm)Speed
Full Load
Current
Speed
Control
EVC152-1
EVC -1073
1 Phase 0.169 kW 230 VAC 4120 1.35 A EC
1 Phase
0.1 kW
230 VAC 0 A EC
00
141 0.83
EVC243-1 1 Phase 0.23 kW0 230 VAC 3290 1.65 A EC
EVC262-1 1 Phase 0.50 kW0 230 VAC 3000 2.6 A0 EC
EVC362-1 1 Phase 0.50 kW0 230 VAC 3000 2.6 A0 EC
EVC445-1 1 Phase 0.40 kW0 230 VAC 2010 2.1 A0 EC
EVC446-1 1 Phase 0.87 kW0 230 VAC 2200 4.5 A0 EC
EVC547-3
3 Phase 400 VAC 2100 2.40 A EC
1.350 kW
