VES ecovent EVC073-1 - Table of Contents; Introduc on

2
www.ves.co.uk
This manual must be read in full before Installation, Operation and Maintenance of the units
supplied
Please ensure that this document is passed to the end user. This manual forms an integral part of
the product and should be kept for the working life of the product. Additional copies of this and
supporting documents are available by contacting VES or by visiting www.ves.co.uk and following
the 'Download O & M's' link.
The following symbols used within this document refer to potential dangers, advice for safe
operation or important points of reference
Indicates hazards associated with electric current and high voltages
Indicates hazards that require safety advice for personnel or potential unit/property damage
Indicates important information
Warning
Caution
Important
Important
Conventions
ecovent Heat Recovery Units
page
Introducon ..................................................................................................................................
2
Nomenclature ................................................................................................................................ 3
Receipt of Goods & Handling ........................................................................................................ 4
Installaon ......................................................................................................................................4
Standard Wiring & Fan Installaon .......................................................................................... 10
Maintenance .............................................................................................................................. 17
1
2
3
4
5
6
Contents
The Ecovent® Counterflow series is a range of Heat Recovery units, with dues up to 1.3 m³/s.
Suitable for either plantroom, ceiling void or internal locaons. As standard, each unit will have been
supplied pre-wired to an isolator or fitted control panel, as specified at the me of order.
The standard operang temperature of these units is -20 to +35 °C.
For further technical details regarding dimensions and weights, contact VES on 08448 15 60 60,
quong the sales order (SO) number and the unit type as found on the unit nameplate, or
alternavely visit www.ves.co.uk.
Introducon 1
