er. An improperly sealed lid will result in air
sucked in by the sea water pump of the
engine which again will result in overheat-
ing of the engine.
To prevent damage of the water strainer,
during frost in the winter time, either the
water must be drained or the installation
must be filled with anti-freeze.
Remove the hoses to drain the strainer; the
housing is not equipped with a drain plug.
Take care that during filling with anti-freeze
no anti-freeze is spilled into the waterway.
Anti-freeze is poisonous.
3.0502 5
Cooling water strainer model 330
ENGLISH
Technical data
Material housing : Polypropylene GF
Material strainer
element : HD Polyethylene
Material lid : Styrol/Acrylnitrile SAN
Weight : 0.45 kg (1 lb)
Max. ambient temperature : 75 °C (167°F)
Max. water temperature : 55 °C (131°F)
Max. pressure : 0,5 bar
(50 kPa, 7 psi)
Model Hose connection Maximum capacity
Recommended capacity
in normal use
l/min Imp.Gal/min US Gal/min l/min Imp.Gal/min US Gal/min
FTR330/13 13 mm (1/2”) 50 11 13 23 5 6
FTR330/16 16 mm (5/8”) 80 18 21 35 8 9
FTR330/19 19 mm (3/4”) 120 26 32 51 11 13
FTR330/25 25 mm (1”) 210 46 55 91 20 24
FTR330/32 32 mm (1 1/4”) 330 73 87 143 31 38
FTR33038 38 mm (1 1/2”) 470 103 124 200 44 53
FTR330/38 38 mm (1 1/2”) 460 101 122 195 43 51
