VEVOR DC425 - Page 17

- 16 -
No
Part Description
Qty
No
Part Description
Qty
1
Cable wire
1
37
Gear washer
1
2
Nut M6
1
38
bearing pressure plate
1
3
Left handle
1
39
Screw M4x10
2
4
Screw M5x20
2
40
oil baffle
1
5
Cable sheath
1
41
Gear
1
6
Tension
1
42
Nut M8
1
7
wiring buckle
2
43
oil baffle
1
8
switch
1
44
Gear box
1
9
right handle
1
45
Screw M5x25
4
10
M6 washer
1
46
Handle
1
11
Screw M6x25
1
47
Sctew M6x45
4
12
Screw ST4x15
8
48
Key 4x4x14
1
13
Screw ST5x24
4
49
Drive shaft
1
14
Motor End Cover
1
50
Key 3x3x14
1
15
Screw ST4x15
2
51
Bearing 6301RS
2
16
Soft Starter
1
52
gear
1
17
Motor Housing
1
53
Nut M8
1
18
Bearing 609 RS
1
54
Breakwater
1
19
Stator
1
55
spring washer M12
1
20
Screw ST5x80
2
56
Screw M12x15
1
21
Spring
2
57
Fixed plate
1
22
Brush Holder
2
58
Screw M6x16
4
23
Screw ST4x10
2
59
Lockpin
1
24
Brush
2
60
Lockpin-spring
1
25
Brush cover
2
61
Circlip for shaft 6
1
26
Screw ST3x8
2
62
Gear box
1
27
Rotor
1
63
Bearing 6200Z
1
28
baffle
1
64
oil baffle
1
29
Bearing washer
1
65
Circlip for shaft 15
1
30
Bearing 6202 RS
1
66
Axle sleeve
1
31
Gear box
1
67
Bevel gear
1
