Note:
1. See the above figure, the fixing ring is placed around the lower stem,
and its flat side faces the upper stem.
2. The two protrusions on the inner surface of the threaded ring must fit into
the two holes near the lower end of the upper stem.
3. If you want to use the arm cuff, insert it into the corresponding hole
beside the handle to a desired depth and then pull down the end of the arm
cuff lock to lock the arm cuff. Once inserted, the arm cuff can not be
disconnected from the upper stem.
4. To avoid damage, do not pull the search coil cable with force. When
connecting the cable to the socket on the rear of the control box or
disconnecting the cable from the socket, hold the cable plug instead of the
cable.
1. Meter
Used to indicate the operating status of the detector.
2. Earphone Jack
3. ALL METALS/DISC Knob
