1. Power Switch: This switch turns the amplier on or off.
2. Pentode/Standby/Triode: The Triode setting reduces the amplier’s maximum output power to approximately one-half of the Pentode set-
ting. Triode setting produces a richer and smoother tone, with earlier breakup than the Pentode setting. The middle position is Standby mode.
3. Watts Control: The Watts control adjusts the output tube’s operating voltage and maximum output power. Maximum output power ranges
from less-than 1 watt (fully counterclockwise) to 12 or 20 watts (fully clockwise).
4. Jewel Light: This light will be illuminated when the Power Switch is in the On position; the jewel light will be off when the Power switch is in
the Off position.
CONTROL PANEL FEATURES
VHT SPECIAL 12/20 FEATURES
12-20 Watts Maximum Output Power
High/Low Tube Voltage Switch
Two 6V6 Output Tubes
Accepts EL84 Ourput Tubes*
Also Accepts 6L6 or EL34 Output Tubes
Three 12AX7 Preamp Tubes
Volume and Tone Controls
Footswitchable Boost Mode
Effects Loop Send and Return Level Controls
Tube-Driven Effects Loop
Tube-Driven Preamp Line Out
6-Position Depth Control
3-Position Texture Switch
Pentode/Standby/Triode Switch
Watts Control
9V DC Out Power Supply
12” VHT ChromeBack Speaker, 60-watt, 16 ohm (Combo Only)
Switchable 4, 8, or 16 Ohm Speaker Output
Mod-Friendly Eyelet-Type Board
Hand-wired
*With VHT 6V6-to-EL84 Socket Adapters
