Preparation Before Taking
Measurement
Install four “AAA” alkaline batteries by following the + (positive) and
- (negative) polarities indicated on the battery compartment.
02
Insert the air plug into air jack on the left side of main unit. Insert the cable
connector of ECG Pen to ECG port on the right side of main unit.
BP700X / BP700X1
Note : Four new “AAA” alkaline batteries will last for approximately 300 measurements.
To Next Page
