Technical Reference Manual
Vmax Encore
L2707
3–29
Chapter 3 Maintenance and Troubleshooting
REPLACEMENT PARTS
Vmax Encore 62J/62W Replacement Parts
Cable extension, Vmax to Autobox 775365
Cable, MFS, Autobox 775363-102
Hose, breathing 22mm 40” 774611-102
Hose, breathing 22mm 78” 774611-101
Hose, high pressure, Autobox 769527
Hose, white 35093
Mass Flow Sensor 775274
Pressure sense line, Autobox 769524-101
Sample line, Autobox 769525
Tube, 2 lumen, Autobox 769521-102
Tube, 4 lumen, Vmax to Autobox 769526
Valve, 3-way Autobox 775321
Part Description Part No.
Adapter, 22mm x 30mm, canopy 775325
Adapter, FRC
Plugs into Syringe and Mass Flow Sensor Mouth Port for FRC Piston Verifications
769296
Adapter, IEC Power; Cord set, HP Deskjet
IEC M to US F, 6 In. Adapts HP Deskjet Power Transformer to plug into IEC Isolation
Transformer
769299
Adapter, Max Pressure
Fits into the Breath-by-Breath port of the Mass Flow Sensor. Used as a Calibrated leak for the
Min Max Respiratory Pressures tests
769692
Arm assy. for console 775141
Cable assembly, external flow, Vmax Encore 62J/62W M 775365
Cable assembly, flow meter 12 pin to 9 Vmax Encore 62J/62W M 775363-102
Cable assembly, flow meter, 12 pin to 9 Vmax M 775363-101
Cable, Module Interface
37 Pin “D” M/F, Right Angle, 9.5 In. Molded. Connects Analyzer Assembly SOL OUT 1 to
Pneumatics Assembly SOL IN
769800
Cable, PC Interface, Console/Table
25 Pin “D” M/M 6 Ft. Connects PC’s Printer Port to Vmax Encore Analyzer Assembly’s I/O Port
(I/O 1, 2, or 3) when Configured as Vmax Encore Console or Table Top System
770796
