04
Before you begin the assembly, remove
all of the contents from the box and make
sure that you have all the parts listed and
in correct quantities. This will ensure the
quickest and most organized assembly.
An electric screwdriver can be used in
the assembly. Set it to a very low torque
and use with extreme caution to prevent
damage to the product.
Assembly.
www.viavito.com
Assembly Frame
x1
x2
#1
Support Brace
#2
Leg Panel
#3
Leg Type A
#4
Leg Type B
#5
Leg Leveler
#9
#6
Support Strut
Stop Ring
#10
Metal Plate with Ring
#7
Rod Bumpers
#11
Metal Plate
#8
Plastic Rod Washer
#12
Players
#13
Rod Handle
#14
Rod End Cap
#15
Ball Entry Cup
#16
x1
x2
x4
x8
x2
x2
x16
x8
x2
x4
x16
x2
x4
x22
Contents Checklist
To Next Page
