VICI VC837 - AC Voltage (ACV) Specifications; DC Current (DCA) Specifications; AC Current (ACA) Specifications; Resistance (Ω) Specifications

6V
±(0.8%+6)
1mV
60V 10mV
600V ±(1.0%+6) 100mV
Input impedance: 10MΩ.
Overload protection: 600V DC/ AC rms.
Frequency response: at 600V range: (40~1000)Hz, at other ranges: (40~2000)Hz
Displaying: True RMS response (calibration based on sine wave RMS)
3.2.4 DC Current
（
DCA
）
Range Accuracy Resolution
600uA
±(1.0%+5)
0.1μA
6000uA 1μA
60mA 10μA
600mA 100μA
6A 1mA
10A ±(2.0%+5) 10mA
Maximum voltage drop: 200 mV for full range.
Maximum input current: 10A (within 10 seconds).
Overload protection: 0.5A/250V fuse and 10A/250V fuse.
3.2.5 AC Current (ACA)
Range Accuracy Resolution
600uA
±(1.5%+5)
0.1μA
6000uA 1μA
60mA 10μA
600mA 100μA
6A 1mA
10A ±(2.0%+10) 10mA
Maximum voltage drop: 200 mV for full range.
Maximum input current: 10A (within 10 seconds).
Overload protection: 0.5A/250V fuse and 10A/250V fuse.
Frequency response: 10A range: 40~100Hz, other ranges: 40
～
400Hz.
3.2.6 Resistance（Ω）
Range Accuracy Resolution
600Ω ±(0.8%+5) 0.1Ω
6kΩ
±(0.8%+1)
1Ω
60kΩ 10Ω
600kΩ 100Ω
6MΩ 1kΩ
60MΩ ±(1.2%+5) 10kΩ
Open circuit voltage: 500mV
Overload protection: 250V DC/AC peak value.
3.2.7 Capacitance (C)
Range Accuracy Resolution
60nF ±(2.5%+6) 10pF
600nF ±(2.5%+5) 100pF
