Vicon V3030APT - Page 10

REFERENCEREFERENCE
DESIGNATIONDESIGNATION
--
PlPl
Rl,R2Rl,R2
21-2421-24
----
JlJl
TB 1 ,TB2TB 1 ,TB2
CI,C2CI,C2
I mm L/ml P/T-ml TILT
‘%d
Figure 8
Parts Location Diagram
REPLACEMENT PARTS LIST
PART NUMBER DESCRIPTION
1204-3076-01
8000-9728-01
8002-8531-00
8004-9325-00
PCB assembly, pan and tilt
Connector, PCB, male, 24-pin, AMP
I-87563-2
Resistor, 220 ohm, l/4 W, 5%
Varistor, V68ZA2 or 14K 241U or
ERZ-C07DK680
1204-3076-02
8000-9728-01
8004-8081-00
PCB assembly, base plate
Connector, PCB, male, 24-pin, AMP
l-87563-2
Terminal strip, 12-position, Buchanan
SSB4-S- 12-S-NN
1802-0049-01
Capacitor 4.0 uF 100 VDC, polyester
