CONNECTORS AND CONTROLS
-
@
@
@
0
Video output connector (BNC)
l,OVp-p/758
composite video signal is provided at this
connector,
@ Power input connector(screw terminal)
AC24V
AC AC
Back of camera
This terminal accepts 24
“AC
power source.
Recommended Power Supply:
Minimum 300
mA
or 7.2 W
Cautions:
1. Connect to a class 2 power supply only.
2, To prevent fire or shock hazard, UL listed wire VW-l, style
1007, should be used for the cable.
@
Autoiris
lens connector for video-drive lens.
This connector supplies 9 VDC power and video signal without
sync, for video-drive type
autoiris
lens.
PIN
Signal
1
GROUND
2
POWER SUPPLY
(9 VDC,
40 mA)
1
2
3
Back of camera
3
VIDEO OUTPUT (0.7 Vp-p without sync)
-
5
-
