ICONNECTORS
AND
CONTROLS
-
8
0
8
@
Autoiris
lens connector for DC drive lens
This connector supplies the contort signals to the DC drive
autoir is lens.
Autoiris
lens cable
If the cable is thick
or the
plug
cover
does not fit properly,
cut this rib away
Lens plug (supplied)
3 Drive(+)
4
4
Drive(-)
0
Power indicator LED
E4-191
J-100
This LED turns ON only when power is supplied properly and
the DC-DC converter (or the regulator) inside the camera
works wel I.
@ ALC level adjustment potentiometer for DC drive lens.
This potentiometer is used only if the camera is fitted with a
DC-drive
autoiris
lens. It is used to control the amount of
light striking the CCD image sensor.
LENS-
IRIS level
LEVEL
I
Monitor screen
LEVEL control direction
To increase the brightness
clockwise
To decrease the brightness
counterclockwise
-
6
-
