CONNECTORS AND CONTROLS
-
0
@I
0
AWB HOLD push button
l Use the AWB HOLD Push Button :
1,
When a subject is I ighted by many kinds of light.
2. When you use a special lamp, such as a sodium lamp or
mercury vapor lamp.
l How to use :
1. Select AWB of model select switch No, 8 (ATW/AWB)
2. Display a full screen of white paper or white subject on
the monitor.
3, Adjust the screen color to be white pushing AWB HOLD
Push button.
@I
MODE SELECT SWITCH
.
1,
LL/INT sw
/
tch
This camera can operate independently, using its internal
crystal-controlled sync generator, or it may be synchronized
using I ine-locking.
To select one or the other of these sync modes, set the DIP
switch on the rear panel to either LL or INT.
If line-locking is selected, al I the cameras in the system
must be adjusted to begin the video field scan at the same
time. This is described in the following procedures
(8,
@J).
2.
NOT USED.
-7-
