FEATURES DEFINITIONS
9
Unit Details - VPLV0226
19.Upper Vac Intake Tube
20. Lower Vac Intake Tub
e
15. Harness
17. Catcher Bag
16. Vac Exhaust Tube
14. Impeller cover
13. STOP Switch
7. Fuel Cap
2. Upper Handle
6. Fuel Tank
18. Impeller cover knob
3. Air Filter
4. Choke
12. Blower Air Tube
1. Throttle control
8. Starter Cord
*Shown in blower configuration
10. Spark Plug
9. Lower Handle
5. Primer Bulb
(beneath air filter)
11. Blower Nozzle
